Omni3D – OmniSTART

Easy to use desktop 3D Printer designer for customers who are just starting their adventure with 3D Printing!

Add to wishlist Adding to wishlist Added to wishlist
Categories,

Key Features

THE EXTRUDER IS MADE OF ALUMINIUM

The extruder is made entirely of high-quality aluminium, which ensures stable and more accurate operation.

FLEXIBLE MAGNETIC BUILDMAT

A removable, magnetic pad is inserted as a printing surface on a bed. Because of the pad high flexibility, it is very easy to remove the prints after work is done. This operation requires no additional tools.

METAL BODY CONSTRUCTION

Printer housing made of aluminium alloy ensures device stability and helps prevent shaking even when printing with a speed of 100 mm/sec. Thus, even during high-speed operation, it is possible to provide high quality and precision printing.

Specifications

Print technology: FFF (fused filament fabrication)
Build volume XYZ: 200 x 200 x 150 mm
Chamber : open, optional top cover
Min. layer height: 50 μm
Max head temperature 260 °C
Number of printing heads: 1
Drive type: Screw drives in all axes
Nozzle diameter: 0,4 mm (optionally 0,6 / 0,8 mm)
Filament diameter:  1,75 mm
Connectivity Wi-Fi/USB Memory/USB Cable
Precision: +/- 100 microns
Automatic platform calibration: No
Nozzle type: Brass
Operating Systems: Windows 7 and later,
MAC OS10.6.8 or later
Max. platform temperature: 100 °C
User interface: 3,5″ Full Color
Resume after losing power: No
Compatible files: .stl, .obj, .3mf, .gcode
Power Supply: 100-240V/320W
Printer dimensions: 395 x 400 x 425 mm
Printer weight: 22 kg
Warranty: 12 months(with the option of prolonging)
