ULTIMAKER S3

Easy-to-use 3D printing starts here

CategoryUltimaker

Description

The Ultimaker S3 is a dual extrusion 3D printer that delivers high-quality, composite-ready performance – in a smaller footprint. Packed with our latest technology, the Ultimaker S3 is as easy to use as it is powerful, offering the most cost-effective way for disruptive businesses to adopt in-house 3D printing.

A more reliable 3D printing experience.

Active bed leveling ensures great adhesion for every print, while sensors constantly monitor material flow while printing. Combine with rigorously tested print profiles in Ultimaker Cura software, and you don’t just have a 3D printer – it’s a complete production system to depend on.

Key Features

Network connectivity: Print via Wi-Fi, LAN, cloud, or with USB
Touch screen: Effortless operation via an award-winning user interface
Advanced active leveling: Reliable first-layer adhesion, enables unattended use
Front enclosure: Improved printing environment for better print results
Flow sensor: Stay informed when filament runs out to increase the print success
Easy setup and monitoring: With NFC material recognition and internal camera
Composite materials compatible: Print parts with high strength and unique properties

Specifications

Technology:	Fused filament fabrication (FFF)
Print head:	Dual extrusion print head with a unique auto-nozzle lifting system and swappable print cores
Build volume (XYZ):	230 x 190 x 200 mm
Layer resolution:	0.25 mm nozzle: 150 – 60 micron, 0.4 mm nozzle: 200 – 20 micron 0.6 mm nozzle: 300 – 20 micron, 0.8 mm nozzle: 600 – 20 micron
XYZ resolution:	6.9, 6.9, 2.5 micron
Build speed:	< 24 mm³/s
Build plate:	Heated glass build plate (20 – 140°C)
Nozzle diameter:	0.4 mm (included) 0.25 mm, 0.6 mm, 0.8 mm (sold separately)
Operating sound:	< 50 dBA
Connectivity:	Wi-Fi, LAN, USB port
Dimensions (with Bowden tubes and spool holder):	394 x 489 x 637 mm
Net weight:	14.4 kg
Supplied software:	Ultimaker Cura, our free print preparation software Ultimaker Digital Factory, our cloud-based printer management solution
Supported OS:	MacOS, Windows, and Linux
Warranty period:	12 months

Why ULTIMAKER

3D Printers that Simply work

Our award-winning 3D printers are robust, reliable, and easy to use. They deliver quality parts time and again. Designed and tested to run 24/7, they allow you to achieve the results you need more quickly and easily.

Software ready for
Industry 4.0

Trusted by millions of users across 14 languages, Ultimaker
Cura integrates with any workflow through Ultimaker marketplace plugins. Then scale production and digital distribution with Ultimaker Digital Factory.

Material choice like
never beforeUltimaker offers the widest material choice on the market. Through our Material Alliance, choose the perfect filament for your application – from advanced polymers to carbon fiber composites.

Support dedicated to
your success

Wherever you are in the world, Ultimaker support is close by. Our global network of service partners offers professional installation, training, and maintenance in your language and time zone.
