Intamsys – Funmat HT

Entry Level Desktop Industrial 3D Printer

Add to wishlist Adding to wishlist Added to wishlist
Category

Description

The FUNMAT HT is an affordable, high-performance 3D printer with a build volume of 260 x 260 x 260 mm. Achieve 50-micron high-resolution industrial quality 3D printing of the FUNMAT HT.

The advanced thermal system design of this 3D printer includes:
90°C constant temperature chamber
160 °C heated build plate
450 °C high-temperature extruder with an all-metal hot end

Key Features

Advanced Thermal Design

Heated Chamber Up to 90℃ (194℉), Hotend Up to 450℃ (842℉)

Smarter Design

Automatic Leveling, Filament Absence Warning

Over 20 Functional Materials

Able to Print PEEK/PEKK/ULTEMTM (PEI)/PPSU and other Functional Materials

Technical Specifications

Model FUNMAT HT
Printing Technology Fused Filament Fabrication (FFF)
Machine Size 543×501×663mm (21.4×19.7×26.1in)
Build Volume 260×260×260mm (10.2×10.2×10.2in)
Build Platform PI Sheet Heating + Ceramic Glass
Leveling Automatic Leveling
Layer Thickness 0.05-0.3mm
Max Travel Speed Max. 300mm/s
Extruder Temperature Max. 450°C/842°F
Platform Temperature Max. 160°C/320°F
Chamber Temperature Max. 90°C/194°F
Input File Type STL/OBJ
Filament Diameter 1.75mm
Position Resolution XY: 12.25μm Z: 1.25μm
Motor Drive High Performance Independent Drivers
Safety Certification FCC/SGS/CE
Supported Materials PEEK/PEEK-CF/ PEEK-GF/PEKK/ULTEMTM (PEI)*/PPSU*/PC/PC Alloys/PA/
PA-CF/ASA/ABS/HIPS/TPU/PETG/PLA/Carbon Fiber-Filled/Glass Fiber-Filled/
ESD-Safe, etc.
